J Lane Speed Plates - Quarter Plate Film - ISO 25

Sold Out

100444

Description

Dry Plates for replicating photographic techniques and results from the 1880s! Wonderful glass plates, a true piece of history for the modern world.

Please note a couple of important points and there is much greater detail on recommend usage and tips below the specs table:

  • these plates are designed to fit dry plate holders which are different from sheet film holders - please ensure you are using the correct equipment to get the great results!
  • note the ISO is low :-) but if you're after something more true to the original technology then check out the J Lane dry plates (ISO 2)

Specification

Format: Quarter Plate: 3.25" x 4.25"
Colour: B&W
Type: Dry Plate
ISO: 25
Exposures: 10
Pack size: 1



More Details for J Lane Speed Plates

These plates are coated with an ultra fine-grain, high contrast orthochromatic emulsion with response from UV through the visible spectrum up to 610 nm. The high contrast is excellent for alternative process printing or for printing onto multigrade paper at grade 0. The long toe of the characteristic curve preserves shadow details for scanning. As with other primitive processes, the effective speed of the plate will vary depending on actual UV levels. The emulsion has been designed to meter at ASA 25 under early spring northward lighting at moderate latitudes, but expect actual speed to vary by up to a stop or more.

OPEN BOX ONLY UNDER SAFELIGHT!

The unexposed plates can be viewed and loaded under any darkroom safelight suitable for photographic paper. A locating notch similar to that used for sheet film is provided for locating the emulsion side of the plate. Orient the Plate with notch at top right and emulsion will be facing you.

Tray Develop under safelight 5 minutes at 68°F in HC-110 Dil B.

Developing by inspection, do not pull the plates until details are visible in the shadows.

  • 30 second agitation at start
  • 15 second agitation every 1 min after.

Acid or water Stop 30 seconds.

Rapid fix, same as for film, constant gentle agitation

  • Fix for double the clearing time, approximately 4 minutes

30 second water bath rinse

Hypo clearing wash 4 minutes if desired

Gentle agitation rinse in room temperature water

  • 5 minutes if hypo washed
  • 10 minutes if not hypo washed

Final dip rinse in photo-flo solution, set vertically to air dry.

Emulsion will be visibly swollen and shiny while still wet.

The non-emulsion “glass side” may have excess emulsion remaining from the hand-coating process. After developing, this excess emulsion can be removed with dilute bleach, disinfecting wipes, or equivalent. Easier to remove when wet.
